38
Seats
! Registration of the reverse tilt-
down mirror angle with button
“1” or “2”
S01AQ060306
CAUTION
Depress the brake pedal when re-
gistering the reverse tilt-down mir-
ror angle.
1. Move the select lever to the “R”
position, then the outside mirror angle will
move to the reverse tilt-down position.
2. Adjust the outside mirror angle. For
details about the settings, refer to “Remote
control mirror switch” FP249.
3. Move the select lever to the “P”
position, then the outside mirror angle will
return to its original position.
4. Press and hold the “SET” button, then
press button “1” or “2” to register the seat
position.
A chirp will sound once, and the outside
mirror angle will be registered.
NOTE
The factory setting (default setting) for
this function is set as the front passen-
ger’s side mirror. The setting of the
right and left side mirror/front passen-
ger’s side mirror operation can be
changed by a SUBARU dealer. Contact
your SUBARU dealer for details.
! Registration of seat position with
a key fob
! Registration of the reverse tilt-
down mirror angle with the key
fob
S01AQ060307
CAUTION
S01AQ060302
1. Adjust the seat position under the
following conditions.
. The parking brake is applied.
. The ignition switch is in the “LOCK”/
“OFF” position.
. The select lever is in the “P” position.
2. Hold the access key fob and press and
hold the “SET” button, then press the “ ”
button of the access key fob.
A chirp will sound once, and the seat
position is registered.
Depress the brake pedal when re-
gistering the reverse tilt-down mir-
ror angle.
1. Move the select lever to the “R”
position, then the outside mirror angle will
move to the reverse tilt-down position.
2. Adjust the outside mirror angle. For
details about the settings, refer to “Remote
control mirror switch” FP249.
3. Move the select lever to the “P”
position, then the outside mirror surface
will return to its original position.
4. Turn the ignition switch to the “OFF”/
“LOCK” position.
5. Hold the access key fob and press and
hold the “SET” button, then press the “ ”
button of the access key fob.
A chirp will sound once, and the reverse
tilt-down mirror angle will be registered.
NOTE
. The factory setting (default setting)
for this function is set as the front
passenger’s side mirror. The setting of
