Seat, seatbelt and SRS airbags
1-31
anchorages (bars) for the position where
you want to install the child restraint
system.
2. While following the instructions supplied by the child restraint system manufacturer, connect the lower hooks onto the
lower anchorages. When the hooks are
connected, make sure the adjacent seatbelts are not caught.
3. [If your child restraint system is of a
flexible attachment type (which uses
tether belts to connect the child restraint
system properly to the lower anchorages)]
While pushing the child restraint into the
seat cushion, pull both left and right lower
tether belts up to secure the child restraint
system firmly by taking up the slack in the
belt.
4. Connect the top tether hook to the
tether anchorage and firmly tighten the
tether. For information on how to set the
top tether, refer to “Top tether anchorages”
F1-32.
5. Before seating a child in the child
restraint system, try to move it back and
forth and right and left to verify that it is
held securely in position.
6. To remove the child restraint system,
follow the reverse procedures of installation.
If you have any question concerning this
type of child restraint system, ask your
SUBARU dealer.
– CONTINUED –
