1-30
Seat, seatbelt and SRS airbags
the rear seat window-side seating positions. For each window-side seating position, two lower anchorages are provided.
Each lower anchorage is located where
the seat cushion meets the seatback.
1)
Your vehicle is equipped with four lower
anchorages (bars) and three upper anchorages (tether anchorages) for accommodating such child restraint systems.
The tether anchorages (upper anchorages) are provided at the locations
shown in the above illustration.
The lower anchorages (bars) are used for
installing a child restraint system only on
Cover
You will find marks “ ” on the cover at the
bottom of the rear seat seatbacks. These
marks indicate the positions of the lower
anchorages (bars).
1. Open the covers of the two lower
