Combination Meter Display( Color LCD) 181 |
||||
|
. After resetting the trip meter, the average rate of fuel consumption is not shown until driving 0.6 miles( 1 km). Until that time, the ECO gauge does not operate.
! Clock and temperature
s03bn1202
This screen displays the clock and outside temperature.
NOTE
. The clock can be displayed in either 12-hour display or 24-hour display. For details, refer to“ Clock” FP226.
. The outside temperature indicator shows the temperature in the area around the sensor. However, the temperature may not be indicated correctly or the update may be delayed in the following conditions.
|
– While parking or driving at low speeds
– When the outside temperature changes suddenly( example: when going in and out of an underground parking area or when passing through a tunnel)
– When starting the engine after being parked for a certain period of time
. You can set the temperature units to be displayed in Fahrenheit( 8F) or Celsius( 8C). For details, refer to“ General settings” FP197( 11.6-inch display models) or“ General settings” FP214( dual 7.0-inch display models).
|
! Compass( if equipped)
s03bn1203
|
The direction of the vehicle is displayed.
! Driving range on remaining fuel s03bn1204
|
3
Instruments and Controls
|
– CONTINUED – |
