362
BSD / RCTA
! When there is a downward slope at the back s07br030102
1 3 ft ( 1 m )
The distance on the screen looks nearer than the actual distance .
NOTE
When cargo is loaded , the rear view distance on the screen looks farther than the actual distance as in an upward slope .
! Feature of distance marker
1 3 ft ( 1 m ) line 2 10 ft ( 3 m ) line s07br0302
The distance marker shows the distance on the road . If there is a car or another object close behind , distance cannot be correctly displayed .
7-20 . BSD / RCTA ( If Equipped ) s07bm
The BSD / RCTA consists of radar sensors with Blind Spot Detection and Rear Cross Traffic Alert .
These functions of BSD / RCTA are the systems that detect objects and vehicles to the rear and draw attention to the driver when changing a lane or when driving in reverse .
WARNING
The driver is responsible for driving safely . Always be sure to check the surroundings with your eyes when changing lanes or reversing the vehicle .
The system is designed to assist the driver in changing lanes or reversing safely by monitoring the rear and side areas of the vehicle . However , you cannot rely on this system alone in assuring the safety during a lane change or reversing . Overconfidence in this system could result in an accident and lead to serious injury or death . Since the system operation has various limitations , the flashing or illumination of the BSD / RCTA approach indicator light
