244
Wiper and Washer
! Windshield washer s03am0104
& Rear Window Wiper and Washer Switch s03am02
The wiper operates only when the ignition switch is in the “ ON ” position .
To wash the windshield , pull the wiper control lever toward you . The washer fluid sprays until you release the lever . The wipers operate while you pull the lever .
Windshield washer fluid warning light
NOTE
The windshield washer fluid warning light appears when the washer fluid level in the tank has dropped to the lower limit . If the warning light appears , refill the tank with fluid . For the tank refilling method , refer to “ Windshield Washer Fluid ” FP483 .
1 Type-A 2 Type-B
: Washer ( accompanied by wiper operation ) : Continuous : Intermittent
OFF / : Off : Washer ( accompanied by wiper operation )
! Rear wiper s03am0201
To turn the rear wiper on , turn the knob switch upward .
To turn the wiper off , return the knob switch to the “ OFF ”/“ ” position .
