Wiper and Washer 245 |
|||||||||
|
With the switch turned to the “ ” position , the rear wiper will operate intermittently at intervals corresponding to the vehicle speed . In this position , when you move the select lever to the “ R ” position , the rear wiper will switch to continuous operation . When you move the select lever from the “ R ” ( reverse ) position to another position , the rear wiper will return to intermittent operation .
Reverse gear interlocked rear wiper :
Even if the rear wiper switch is in the “ OFF ”/“ ” position , if the front windshield wiper is operating continuously , the rear wiper will operate intermittently when you move the select lever to the “ R ” ( reverse ) position .
|
The factory setting ( default setting ) of the reverse gear interlocked rear wiper is operational . |
! Washer s03am0202
To wash the rear window while the rear wiper is operating , turn the knob switch upward to the “ ” position . The washer fluid sprays until you release the knob .
To wash the rear window when the rear wiper is not in use , turn the knob switch downward to the “ ” position . The washer fluid sprays and the wiper operates until you release the knob .
The rear view camera washer also operates while the rear window washer is operating .
|
lower limit . If the warning light appears , refill the tank with fluid . For the tank refilling method , refer to “ Windshield Washer Fluid ” FP483 . |
3
Instruments and Controls
|
|||||
This setting can be changed by a SUBARU dealer . Consult your SUBARU dealer for details . |
|||||||||
|
CAUTION
Do not attach anything that disturbs the rear wiper operation on the rear gate . Doing so may damage the rear wiper when it operates .
|
Windshield washer fluid warning light
NOTE
The windshield washer fluid warning light appears when the washer fluid level in the tank has dropped to the
|
