3-48
Instruments and controls / Multi-function display ( black and white )
through a tunnel ) – When starting the engine after being parked for a certain period of time . The temperature unit cannot be changed .
! Road surface freeze warning indication
S03BO0101
1 ) |
U . S . -spec. models |
2 ) |
Except U . S . -spec. models |
When the outside temperature drops to a certain temperature or lower , the temperature indication flashes for 5 seconds to show that the road surface may be frozen .
If the display is already indicating that the outside temperature is low when the ignition switch is turned to the “ ON ” position , the indication does not flash .
NOTE
The outside temperature indication may differ from the actual outside temperature . The road surface freeze warning indication should be treated only as a guide . Be sure to check the condition of the road surface before driving .
& X-MODE indicator ( if equipped )
S03BO12
This indicator will be shown while the X-MODE is activated . It will turn off when the X-MODE is deactivated .
& Clock
S03BO10
For details about clock setting , refer to “ Clock ” F3-66 .
& Climate control screen
S03BO13
The climate control status is displayed on the multi-function display ( black and white ) type A .
Climate control screen |
1 ) |
Set temperature indicator |
2 ) |
FULL AUTO indicator |
3 ) |
AUTO indicator |
4 ) |
Air conditioner ON indicator |
5 ) |
Airflow mode indicator |
6 ) |
Air inlet selection indicator |
7 ) |
Fan speed indicator |
When operating the climate control system , the basic screen switches to the climate control screen . For details about climate control operation , refer to “ Climate control panel ” F4-2 .
