Instruments and controls/Combination meter display (color LCD)
Combination meter display
(color LCD) (if equipped)
6)
S03BN
7)
WARNING
8)
Always pay adequate attention to
safe driving when operating the
combination meter display (color
LCD) while the vehicle is in motion.
When operation of the combination
meter display (color LCD) interferes
with your ability to concentrate on
driving, stop the vehicle before
performing operations on the
screen. Also, do not concentrate on
the display while driving. Doing so
may cause you to look away from the
road and could result in an accident.
Various information will be shown on the
combination meter display (color LCD).
Also, a warning message will appear on
the display if a malfunction, etc. is
detected. In addition, several settings for
the displayed content can be performed.
9)
A:
B:
3-33
F3-35.)
Select lever/gear position indicator (refer
to “Select lever/gear position indicator
(CVT models)” F3-30.)
X-MODE indicator (if equipped) (refer to
“X-MODE indicator” F3-32.)
Odometer (refer to “Odometer” F3-9.)/
double trip meter (refer to “Double trip
meter” F3-9.)
Fuel gauge (refer to “Fuel gauge” F3-
10.)
Deactivating the Eyesight system or
models without the Eyesight system
Activating the Eyesight system
Combination meter display (color LCD)
1) ECO gauge
2) Warning screen (refer to “Warning
screen” F3-35.)/Basic screen (refer to
“Basic screens” F3-36.)
3) EyeSight screen
4) Cruise control information display
5) Telltale screen (refer to “Telltale screen”
– CONTINUED –
