3-32
Instruments and controls / Warning and indicator
& X-MODE indicator( if equipped)
S03AE68
This indicator appears while the X-MODE is activated. It will disappear when the X- MODE is deactivated. Refer to“ To activate / deactivate the X-MODE” ☞7-39.
& Hill descent control indicator( if equipped)
S03AE69
This indicator appears while the hill descent control function is in standby. It will flash while the hill descent control function is operating. It will disappear when the hill descent control function is not available. Refer to“ Hill descent control function” ☞7- 40.
& BSD / RCTA warning indicator( if equipped)
S03AE80
This warning indicator appears when the BSD / RCTA is malfunctioning. In this case the BSD / RCTA warning indicator will be shown on the combination meter display( color LCD). When this indicator appears, have your vehicle inspected by your SUBARU dealer as soon as possible.
& BSD / RCTA OFF indicator( if equipped)
S03AE86
The indicator appears when the BSD / RCTA OFF switch is pressed to deactivate the BSD / RCTA, or when the BSD / RCTA is suspended temporarily. In this case the BSD / RCTA OFF indicator will be shown on the combination meter display( color LCD). For details, refer to“ BSD / RCTA” ☞7-53.
& RAB warning indicator( if equipped) S03AE91
This indicator illuminates if the Reverse Automatic Braking System malfunctions. Refer to“ Reverse Automatic Braking System” ☞7-62.
& RAB OFF indicator light( if equipped) S03AE92
This indicator illuminates when the Reverse Automatic Braking System is turned OFF, or when the Reverse Automatic Braking System is suspended temporarily. Refer to“ Reverse Automatic Braking System” ☞7-62.
& Icy road surface warning indicator( if equipped)
S03AE82
When the outside temperature is 378F( 38C) or less, the icy road surface warning will illuminate to inform the driver that the road surface may be frozen.
NOTE
. The outside temperature indicator shows the temperature in the area around the sensor. Therefore, the temperature indication may differ from the actual outside air temperature.. The icy road surface warning screen should be treated only as a guide. Be sure to check the condition of the road surface before driving.. Once the icy road surface warning screen appears, it will not disappear unless the outside temperature has increased to 418F( 58C) or higher.
