Child restraint systems 83 |
|||||||
Second-row seat ( bench seat ) |
Second-row seat You will find marks “ ” at the secondrow seat cushion . These marks indicate the positions of the lower anchorages ( bars ). Each lower anchorage is located behind the cover of seatback bottom . Third-row seat You will find marks “ ” at the bottom of the third-row seat seatbacks . These marks indicate the positions of the lower anchorages ( bars ). |
system because the anchorage cover returns to the original position , press the anchorage cover to the seat cushion until it is flat .
4 . If the child restraint system makes contact with the head restraint of the rear seating position where the child restraint system is to be installed , raise the head restraint to the extended position . If the child restraint system still makes contact , remove the head restraint . For details , refer to “ Head restraints ” FP48 .
|
CAUTION |
Seat , seatbelt and SRS airbags |
|||
Store the head restraint that has been removed in the cargo area . Do not place the head restraint in the passenger compartment to prevent it from being thrown around in the passenger compartment in a sudden stop or a sharp turn . |
|||||||
|
Third-row seat
2 . Refer to the “ ” marks to position the lower anchorages ( bars ). The location of the symbols may vary according to the vehicle model .
|
3 . For second-row seat , peel off the anchorage cover completely from the selected side of the second-row seatback to expose the anchorages ( bars ) to be used for installation of the child restraint system . If it is hard to install the child restraint |
||||||
– CONTINUED – |
