84
Child restraint systems
5 . While following the instructions supplied by the child restraint system manufacturer , connect the lower hooks onto the lower anchorages located at “ ” marks on the bottom of the rear seatback . When the hooks are connected , make sure the adjacent seatbelts are not caught .
6 . If there is a gap between the child restraint system and the seatback , adjust the seatback angle until good contact is achieved .
7 . If your child restraint system is a flexible attachment type ( which uses tether belts ), push the child restraint system into the seat cushion and pull both left and right lower tether belts up to secure the child restraint system by taking up the slack in the belt .
8 . Latch the tether hook onto the tether anchorage that is located behind the second-row and third-row seat and tighten the tether firmly . For additional instructions , refer to “ Tether anchorages ” FP85 .
9 . Before having a child sit in the child restraint system , try to move it back and forth and right and left to check if it is firmly secured . Sometimes a child restraint system can be more firmly secured by pushing it down into the seat cushion . It should not be possible to move the child restraint system more than 1 in ( 2.5 cm ).
10 . To remove the child restraint system , follow the reverse procedures of installation .
