378
BSD / RCTA
tive, even if there is a vehicle traveling in a neighboring lane or approaching your vehicle from either side.
The driver is responsible for paying attention to the rear and side areas of the vehicle.
The system uses radar sensors for the above functions.
NOTE
The BSD / RCTA radar sensor has been certified by the radio wave related laws of the U. S. and other FCC compliant countries and Canada. When driving in other countries, certification of the country where the vehicle is driven must be obtained. For certification in the U. S. and other FCC compliant countries and Canada, refer to“ Certification for the BSD / RCTA” FP384.! Blind Spot Detection( BSD)
S07BM0101
& System features
S07BM01
BSD / RCTA consists of the following functions.
. To detect a vehicle in a blind spot on an adjacent lane or a vehicle approaching at high speeds( Blind Spot Detection)
. To detect a vehicle approaching from the right or left while reversing the vehicle( Rear Cross Traffic Alert)
1 Operating range
The system warns the driver of dangers as follows.
. If the system detects a vehicle in the blind spot, the BSD / RCTA approach indicator light( s) on the outside mirror( s) will illuminate.
BSD / RCTA approach indicator light
. If the driver operates the turn signal lever in the direction which the BSD / RCTA approach indicator light is illuminating, the corresponding BSD / RCTA approach indicator light will flash.
