BSD / RCTA 377 |
||||||
|
. When starting backward facing uphill. When starting forward facing downhill. While the parking brake is applied
. While the ignition switch is in the“ ACC” or“ OFF” position
|
. While the Vehicle Dynamics Control warning light is illuminated. Refer to“ Vehicle Dynamics Control warning light / Vehicle Dynamics Control operation indicator light” FP182.
When using the Hill start assist system, a braking effect may be felt even after the brake pedal has been released.
CAUTION
The braking power of the Hill start assist system may not be sufficient when strong braking power is needed( e. g., when towing a trailer).
NOTE
A slight jolt may be felt when the vehicle begins to move forward after being reversed.
|
7-16. BSD / RCTA
S07BM
The BSD / RCTA consists of rear corner radars with Blind Spot Detection and Rear Cross Traffic Alert.
These functions enable the system to detect objects or vehicles to the rear, drawing attention to the driver when changing a lane or when driving in reverse.
WARNING
The driver is responsible for driving safely. Always be sure to check the surroundings when changing lanes or reversing the vehicle.
The system is designed to assist the driver to change lanes or reverse safely by monitoring the rear and side areas of the vehicle. However, you cannot rely on this system alone in assuring the safety during a lane change or reversing. Overconfidence in this system could result in an accident and lead to serious injury or death. Since the system operation has various limitations, the flashing or illumination of the BSD / RCTA approach indicator light may be delayed or the warning buzzer may be delayed or inopera-
|
Starting and operating |
|||
– CONTINUED – |
