Surround View Monitor 319
! Checking the rearward
S06BJ0102
When the select lever is move to“ R”, the image in the rearward direction is displayed. Pressing the view monitor switch or touching the view icon while the image of the rear camera is displayed will switch the screen view.
1 Vehicle icon 2 Vehicle angle icon
When the 3D view is displayed, the display angle switches clockwise from the starting position. When the view returns to the starting position, the display angle stops switching. You can also switch the display angle by touching the vehicle angle icon on the screen.
NOTE
If you turn off the Surround View Monitor or change the screen to operate other functions, the next time the image is displayed, it will be displayed at the previously displayed angle.
1 Original screen 2 Rear view screen / Top view screen / Reverse Automatic Braking( RAB) screen
3 Rear view screen / Reverse Automatic Braking( RAB) screen
4 Top view screen
: Shift the select lever.
– CONTINUED –
Interior equipment
