320
Surround View Monitor
: Touch the view icon or press the view monitor switch.
NOTE
. If you turn off the Surround View Monitor or use it to operate another function, the next time the image is displayed, the previously displayed screen will be shown. However, if the top view screen is displayed at that time, the next time the monitor image is displayed, the rear view screen / Reverse Automatic Braking( RAB) screen will be shown.
. When“ Rear Camera Delay Control” is on, the rear-view image will be displayed on the center information display for a certain period of time after the select lever is shifted from the“ R” position to another position( other than the“ P” position). To turn the function on and off, refer to“ General settings” FP208.
! Checking the front
S06BJ0103
When the view monitor switch is pressed while the select lever is in the“ N” or“ D” position, the front view is displayed.
1 Original screen 2 Top view screen
3 Left-side view screen / Right-side view screen / Front-top view screen
4 Front view screen / Front-top view screen
: Press the view monitor switch.: Touch the view icon.
NOTE
If you turn off the Surround View Monitor or use it to operate another function, the next time the image is displayed, the previously displayed screen will be shown.
& How to cancel Surround View Monitor
S06BJ02
There are several ways to cancel Surround View Monitor.
! Manual cancellation
S06BJ0201
The Surround View Monitor will be canceled by either of the following operations.
. Press the view monitor switch until the original screen is displayed( when the select lever is other than the“ R” position).
. Move the select lever to a position other than the“ R” position( when the select lever is in the“ R” position).
. Touch( car settings icon).. Touch( HOME).. Touch( driver profiles icon).! Automatic cancellation
S06BJ0202
If any of the following conditions are met, the Surround View Monitor is canceled automatically.
