256
Mirrors
Rotation adjustment
! Dimming setting
S03AP110306
The Smart Rearview Mirror has a dimming mirror mode. When the mirror mode is selected with the ignition switch in the“ ON” position, auto dimming will activate. This mode decreases glare automatically depending on the brightness level from behind.
1 Setting button: Press the setting button to set the angle.
2 Press this button to turn the angle counterclockwise.
3 Press this button to turn the angle clockwise.
After pressing the setting button, the mode will change to the HomeLink menu.
NOTE
If the button is not touched for 5 seconds, the rotation adjustment menu will finish.
1 Left button 2 Center button 3 Right button
When selecting the mirror mode, press any of the buttons to display the auto dimming menu. Press the center or right buttons to turn the dimming mirror mode ON / OFF.
Dimming mirror mode ON indicator
Dimming mirror mode OFF indicator
When turning the dimming mirror mode ON / OFF, the dimming mirror mode ON / OFF indicator will illuminate for 5 seconds.
