198
Combination meter display ( color LCD )
NOTE
. The welcome screen and the goodbye screen may differ in the actual words and appearance .
. The basic screen will be shown when the ignition switch is turned to the “ ON ” position while the welcome screen is displayed .
. Once the welcome screen appears , it takes a certain period of time to display it again .
. If the ignition switch is operated after unlocking the driver ’ s door , the welcome screen will not appear even when the driver ’ s door is opened and closed .
. The welcome screen will disappear when you lock the driver ’ s door by using the remote keyless entry system ( all models ) or the keyless access function ( if equipped ) while the welcome screen is displayed .
. The welcome screen including the audio / navigation unit can be set to on or off .
. The welcome screen and the goodbye screen can be set to on or off . For details , refer to “ General settings ” FP213 .
& Warning screen
S03BN05
Example of warning
If there is a warning message or a maintenance notification , it will appear on this screen . Take the appropriate actions based on the messages indicated .
& Meter information screen
S03BN12
The meter information screen can be changed . For details , refer to “ General settings ” FP213 .
! ECO gauge
S03BN1201
The ECO gauge shows the difference between the average rate of fuel consumption since the trip meter was last reset and the current rate of fuel consumption .
The ECO gauge indicates the current fuel |
efficiency as shown in the following chart . |
Displayed unit |
Needle position
“+” side
“ − ” side
|
MPG |
Better |
Poorer |
l / 100km |
Poorer |
Better |
NOTE
. The ECO gauge shows only an approximate indication .
. After resetting the trip meter , the
