Combination meter display ( color LCD ) 199 |
|||||||
|
average rate of fuel consumption is not shown until driving 0.6 miles ( 1 km ). Until that time , the ECO gauge does not operate .
! Clock and outside temperature
S03BN1202
This screen displays the clock and outside temperature .
NOTE
. The clock can be displayed in either 12-hour display or 24-hour display . For details , refer to “ Clock ” FP231 .
. The outside temperature indicator shows the temperature in the area around the sensor . However , the temperature may not be indicated correctly or the update may be delayed in the following conditions .
|
– While parking or driving at low speeds
– When the outside temperature changes suddenly ( example : when going in and out of an underground parking area or when passing through a tunnel )
– When starting the engine after being parked for a certain period of time
. You can set the temperature units to be displayed in Celsius ( 8C ) or Fahrenheit ( 8F ). For details , refer to “ Car settings ” FP218 .
! Compass ( if equipped )
S03BN1203
The direction of the vehicle is displayed .
|
! Driving range on remaining fuel
S03BN1204
|
NOTE
The driving range on the remaining fuel is only a guide . The indicated value may differ from the actual driving range on the remaining fuel , so you must immediately fill the tank when the low fuel warning light illuminates .
|
Instruments and controls |
|||
– CONTINUED – |
