Combination meter display ( color LCD ) 197
4 |
Digital speed screen ( Refer to “ Basic |
screens ” FP201 .) |
5 |
Telltale screen ( Refer to “ Telltale screen ” |
FP200 .) |
6 |
Select lever / gear position indicator ( Refer |
to “ Select lever / gear position indicator |
” FP193 .) |
7 |
X-MODE indicator ( Refer to “ X-MODE |
indicator ” FP194 .) |
8 |
Odometer |
( Refer |
to |
“ Odometer ” |
FP171 .)/ Double trip meter ( Refer to |
“ Double trip meter ” FP171 .) |
A : |
Activating the EyeSight system |
B : |
Deactivating the EyeSight system |
& Basic operation
S03BN01
By operating or of the control switches , the screens can be changed .
If there are some useful messages , such as vehicle information , warning information , etc ., they will interrupt the current screen , and appear on the display accompanied by a beep . If such a screen is displayed , take proper action according to the message shown on the screen .
The warning screen will return to the original screen after a few seconds . While the information reminder is shown on the display , it may be possible to display the warning screen again . To recall the message marked with on the display , press the switch on the steering wheel .
Instruments and controls
Combination meter display 1 Meter information screen ( Refer to “ Meter information screen ” FP198 .)
2 Warning screen ( Refer to “ Warning screen ” FP198 .)/ Basic screen ( Refer to “ Basic screens ” FP201 .)
3 EyeSight screen
Control switches 1 2 3
& Welcome screen ( opening animation ) and Good-bye screen ( ending animation )
S03BN08
When the driver ’ s door is opened and closed after unlocking the door , the welcome screen ( opening animation ) will appear on the combination meter display for approximately 20 seconds .
When the ignition switch is turned to the “ LOCK ”/“ OFF ” position , the combination meter display gradually turns off by showing good-bye screen ( ending animation ).
– CONTINUED –
