196
Combination meter display ( color LCD )
& Warning screen |
S03BN05 |
! ECO gauge |
S03BN1201 |
|
average rate of fuel consumption is not shown until driving 0.6 miles ( 1 km ). Until that time , the ECO gauge does not operate . |
|
|
|
|
! Clock and outside temperature
S03BN1202
|
Example of warning
If there is a warning message or a maintenance notification , it will appear on this screen . Take the appropriate actions based on the messages indicated .
& Meter information screen
S03BN12
The meter information screen can be changed . For details , refer to “ General settings ” FP210 .
The ECO gauge shows the difference between the average rate of fuel consumption since the trip meter was last reset and the current rate of fuel consumption .
The ECO gauge indicates the current fuel |
efficiency as shown in the following chart . |
Displayed unit |
Needle position
“+” side
“ − ” side
|
MPG |
Better |
Poorer |
l / 100km |
Poorer |
Better |
NOTE
. The ECO gauge shows only an approximate indication .
. After resetting the trip meter , the
This screen displays the clock and outside temperature .
NOTE
. The clock can be displayed in either 12-hour display or 24-hour display . For details , refer to “ Clock ” FP228 .
. You can set the temperature units to be displayed in Celsius ( 8C ) or Fahrenheit ( 8F ). For details , refer to “ Car settings ” FP215 .
