Combination meter display ( color LCD ) 197
! Compass ( if equipped )
S03BN1203
The direction of the vehicle is displayed .
! Driving range on remaining fuel
S03BN1204
NOTE
The driving range on the remaining fuel is only a guide . The indicated value may differ from the actual driving range on the remaining fuel , so you must immediately fill the tank when the low fuel warning light illuminates .
& Telltale screen
S03BN09
left in ascending order of severity .
. If there are 6 or more warning messages to display , the indicators will be displayed in sequential order .
Mark Name Page
Door open warning light 183
Engine hood open warning light
AT OIL TEMP warning light
All-Wheel Drive warning light
LED headlight warning light
183
178
183
191
Instruments and controls
1 Telltale screen
When the corresponding situation occurs , the following telltales will be displayed on the telltale screen .
NOTE
. When there is warning information to display , it will be displayed in five warning indicators , starting on the
High beam assist indicator light
Steering Responsive Headlight OFF indicator light
Steering Responsive Headlight warning light
Rear differential oil temperature warning light ( if equipped )
191
191
192
178
– CONTINUED –
