Combination meter display ( color LCD ) 195
4
Digital speed screen ( Refer to “ Basic
screens ” FP198 .)
5
Telltale screen ( Refer to “ Telltale screen ”
FP197 .)
6
Select lever / gear position indicator ( Refer
to “ Select lever / gear position indicator
” FP191 .)
7
X-MODE indicator ( Refer to “ X-MODE
indicator ” FP192 .)
8
Odometer
( Refer
to
“ Odometer ”
FP169 .)/ Double trip meter ( Refer to
“ Double trip meter ” FP169 .)
A :
Activating the EyeSight system
B :
Deactivating the EyeSight system
& Basic operation
Control switches 1 2 3
S03BN01
By operating or of the control switches , the screens can be changed .
If there are some useful messages , such as vehicle information , warning information , etc ., they will interrupt the current screen , and appear on the display accompanied by a beep . If such a screen is displayed , take proper action according to the message shown on the screen .
The warning screen will return to the original screen after a few seconds . While the information reminder is shown on the display , it may be possible to display the warning screen again . To recall the message marked with on the display , press the switch on the steering wheel .
& Welcome screen ( opening animation ) and Good-bye screen ( ending animation )
S03BN08
When the driver ’ s door is opened and closed after unlocking the door , the welcome screen ( opening animation ) will appear on the combination meter display for approximately 20 seconds .
When the ignition switch is turned to the “ LOCK ”/“ OFF ” position , the combination meter display gradually turns off by showing Good-bye screen ( ending animation ).
NOTE
. The welcome screen and the goodbye screen may differ in the actual words and appearance .
. The basic screen will be shown when the ignition switch is turned to the “ ON ” position while the welcome screen is displayed .
. Once the welcome screen appears , it takes a certain period of time to display it again .
. If the ignition switch is operated after unlocking the driver ’ s door , the welcome screen will not appear even when the driver ’ s door is opened and closed .
. The welcome screen will disappear when you lock the driver ’ s door by using the remote keyless entry system ( all models ) or the keyless access function ( if equipped ) while the welcome screen is displayed .
. The welcome screen including the audio / navigation unit can be set to on or off .
. The welcome screen and the goodbye screen can be set to on or off . For details , refer to “ General settings ” FP210 .
Instruments and controls
– CONTINUED –
