194
Combination meter display ( color LCD )
NOTE
The Driver Monitoring System stops temporarily in the following circumstances .
. The temperature of the Driver Monitoring System unit is high .
& One-touch Interior Illumination indicator ( if equipped )
S03AEB5
This indicator light illuminates when the One-touch Interior Illumination function is activated . Refer to “ One-touch Interior Illumination function ” FP304 .
3-7 . Combination meter display ( color LCD )
WARNING
S03BN
Always pay adequate attention to safe driving when operating the combination meter display while the vehicle is in motion . When operation of the combination meter display interferes with your ability to concentrate on driving , stop the vehicle before performing operations on the screen . Also , do not concentrate on the display while driving . Doing so may cause you to look away from the road and could result in an accident .
Various information will be shown on the combination meter display . Also , a warning message will appear on the display if a malfunction is detected . In addition , several settings for the displayed content can be performed .
Combination meter display 1 Meter information screen ( Refer to “ Meter information screen ” FP196 .)
2 Warning screen ( Refer to “ Warning screen ” FP196 .)/ Basic screen ( Refer to “ Basic screens ” FP198 .)
3 EyeSight screen
