Warning and indicator lights 193 |
|||||||||||||||||
|
pended temporarily . In this case the BSD / RCTA OFF indicator will be shown on the combination meter display . For details , refer to “ BSD / RCTA ” FP382 .
& RAB warning indicator ( if equipped )
S03AE91
This indicator illuminates if the Reverse Automatic Braking ( RAB ) system malfunctions . Refer to “ Reverse Automatic Braking ( RAB ) system ” FP391 .
|
& RAB OFF indicator ( if equipped )
S03AE92
This indicator illuminates when the Reverse Automatic Braking ( RAB ) system is turned off , or when the Reverse Automatic Braking ( RAB ) system is suspended temporarily . Refer to “ Reverse Automatic Braking ( RAB ) system ” FP391 .
|
& Icy road surface warning indicator
S03AE82
When the outside temperature is 378F ( 38C ) or less , the icy road surface warning will illuminate to inform the driver that the road surface may be frozen .
NOTE
. The outside temperature indicator shows the temperature in the area
|
around the sensor . However , the temperature may not be indicated correctly or the update may be delayed in the following conditions . – While parking or driving at low speeds
– When the outside temperature changes suddenly ( example : when going in and out of an underground parking area or when passing through a tunnel )
– When starting the engine after being parked for a certain period of time
. The icy road surface warning screen should be treated only as a guide . Be sure to check the condition of the road surface before driving .
. Once the icy road surface warning screen appears , it will not disappear unless the outside temperature has increased to 418F ( 58C ) or higher .
|
& Driver Monitoring System operation indicator light ( green ) ( if equipped )
S03AEA4
This indicator illuminates when the Driver Monitoring System is activated . Refer to “ Driver Monitoring System operation indicator light ( green )” FP410 .
|
& Driver Monitoring System warning light ( yellow ) ( if equipped )
S03AEB6
This warning light illuminates if the Driver Monitoring System malfunctions . Have your vehicle inspected at a SUBARU dealer as soon as possible . Refer to “ Driver Monitoring System operation indicator light ( green )” FP410 .
|
& Driver Monitoring System OFF indicator light ( if equipped ) S03AEA5
This indicator illuminates when “ Driver Monitoring System ” is touched to deactivate Driver Monitoring System . Refer to “ Driver Monitoring System OFF indicator light ” FP410 .
|
& Driver Monitoring System temporary stop indicator light ( if equipped )
S03AEA6
This indicator illuminates when the Driver Monitoring System is temporarily stopped . Refer to “ Driver Monitoring System temporary stop indicator light ” FP410 .
|
Instruments and controls |
|||||||||
– CONTINUED – |
