3.0 MODULAR SUPPORT SYSTEM 3.1.2 MT BEAM AND COLUMN LOAD TABLES
Modular Support Systems Technical Guide, Edition 1
Table 49- MT-80 Maximum Factored Beam Loads: X-axis Bending 1, 2, 3, 4, 5
Span in( cm)
Max Factored Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
24
20,935
0.05
20,935
20,935
20,935
( 61.0)
( 93,120)
( 0.14)
( 93,120)
( 93,120)
( 93,120)
36
13,955
0.12
13,955
13,955
11,570
( 91.4)
( 62,070)
( 0.31)
( 62,070)
( 62,070)
( 51,465)
48
10,465
0.21
10,465
9,760
6,505
( 121.9)
( 46,550)
( 0.54)
( 46,550)
( 43,410)
( 28,935)
60
8,370
0.33
8,330
6,245
4,165
( 152.4)
( 37,230)
( 0.85)
( 37,050)
( 27,775)
( 18,525)
72
6,975
0.48
5,785
4,335
2,890
( 182.9)
( 31,025)
( 1.22)
( 25,730)
( 19,280)
( 12,855)
84
5,980
0.66
4,250
3,185
2,125
( 213.4)
( 26,600)
( 1.67)
( 18,900)
( 14,165)
( 9,450)
96
5,230
0.86
3,250
2,440
1,625
( 243.8)
( 23,260)
( 2.18)
( 14,455)
( 10,850)
( 7,225)
108
4,650
1.08
2,570
1,925
1,285
( 274.3)
( 20,680)
( 2.76)
( 11,430)
( 8,560)
( 5,715)
120
4,185
1.34
2,080
1,560
1,040
( 304.8)
( 18,615)
( 3.40)
( 9,250)
( 6,935)
( 4,625)
144
3,485
1.93
1,445
1,080
720
( 365.8)
( 15,500)
( 4.90)
( 6,425)
( 4,800)
( 3,200)
168
2,990
2.63
1,060
795
530
( 426.7)
( 13,300)
( 6.67)
( 4,715)
( 3,535)
( 2,355)
192
2,615
3.43
810
610
405
( 487.7)
( 11,630)
( 8.71)
( 3,600)
( 2,710)
( 1,800)
216
2,325
4.34
640
480
320
( 548.6)
( 10,340)
( 11.02)
( 2,845)
( 2,135)
( 1,420)
240
2,090
5.35
520
390
260
( 609.6)
( 9,295)
( 13.59)
( 2,310)
( 1,730)
( 1,155)
Table 51- MT-80 Maximum Factored Column
Loads 1, 2, 6, 7, 8
Unbraced Height in( cm)
Max Factored Load at Girder Face lbs( N)
K = 0.65 lbs( N)
Maximum Column Load Applied at C. G.
K = 0.80 lbs( N)
K = 1.0 lbs( N)
K = 1.2 lbs( N)
24
17,020
42,875
42,875
42,875
42,875
( 61.0)
( 75,710)
( 190,725)
( 190,725)
( 190,725)
( 190,725)
36
16,615
42,875
42,875
42,875
42,045
( 91.4)
( 73,920)
( 190,725)
( 190,725)
( 190,725)
( 187,035)
48
16,070
42,875
42,875
39,835
34,205
( 121.9)
( 71,485)
( 190,725)
( 190,725)
( 177,200)
( 152,160)
60
15,015
42,875
39,835
32,960
26,760
( 152.4)
( 66,805)
( 190,725)
( 177,200)
( 146,615)
( 119,040)
72
12,365
40,405
34,205
26,760
19,785
( 182.9)
( 55,025)
( 179,735)
( 152,160)
( 119,040)
( 88,010)
84
11,185
35,755
29,220
20,920
14,535
( 213.4)
( 49,770)
( 159,045)
( 130,000)
( 93,070)
( 64,660)
96
10,020
31,715
24,360
16,025
11,130
( 243.8)
( 44,580)
( 141,080)
( 108,375)
( 71,290)
( 49,510)
108
8,870
27,675
19,785
12,660
8,790
( 274.3)
( 39,460)
( 123,110)
( 88,010)
( 56,335)
( 39,105)
120
7,830
23,770
16,025
10,250
7,120
( 304.8)
( 34,845)
( 105,750)
( 71,290)
( 45,605)
( 31,675)
144
( 365.8)
6,190
( 27,540)
16,860
( 75,005)
11,130
( 49,510)
7,120
( 31,675)
**
Table 50- MT-80 Maximum Factored Beam Loads: Y-axis Bending 1, 2, 3, 4, 5
Span in( cm)
Max Factored Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
24
10,535
0.03
10,535
10,535
7,045
( 61.0)
( 46,860)
( 0.07)
( 46,860)
( 46,860)
( 31,335)
36
7,025
0.06
6,265
4,695
3,130
( 91.4)
( 31,245)
( 0.15)
( 27,865)
( 20,880)
( 13,920)
48
5,265
0.11
3,520
2,640
1,760
( 121.9)
( 23,415)
( 0.27)
( 15,655)
( 11,740)
( 7,825)
60
4,215
0.17
2,255
1,690
1,125
( 152.4)
( 18,745)
( 0.43)
( 10,030)
( 7,515)
( 5,000)
72
3,510
0.24
1,565
1,170
780
( 182.9)
( 15,610)
( 0.62)
( 6,960)
( 5,200)
( 3,465)
84
3,010
0.33
1,150
860
575
( 213.4)
( 13,385)
( 0.84)
( 5,115)
( 3,825)
( 2,555)
96
2,630
0.43
880
660
440
( 243.8)
( 11,695)
( 1.09)
( 3,910)
( 2,935)
( 1,955)
108
2,340
0.55
695
520
345
( 274.3)
( 10,405)
( 1.39)
( 3,090)
( 2,310)
( 1,530)
120
2,105
0.67
560
420
280
( 304.8)
( 9,360)
( 1.71)
( 2,490)
( 1,865)
( 1,245)
144
1,755
0.97
390
290
195
( 365.8)
( 7,805)
( 2.47)
( 1,730)
( 1,285)
( 865)
168
1,505
1.32
285
215
140
( 426.7)
( 6,690)
( 3.36)
( 1,265)
( 955)
( 620)
192
1,315
1.72
220
165
110
( 487.7)
( 5,845)
( 4.38)
( 975)
( 730)
( 485)
216
1,170
2.18
170
130
85
( 548.6)
( 5,200)
( 5.55)
( 755)
( 575)
( 375)
240
1,050
2.69
140
105
70
( 609.6)
( 4,670)
( 6.83)
( 620)
( 465)
( 310)
Notes:
1. Loads are based on ICC-ES ELC-5019 and CSA S136-16, the North American Specification for the Design of Cold-Formed Steel Structural Members( using the Appendix B provisions applicable to Canada), CSA Group.
2. Resistance factors for flexure and compression are 0.90 and 0.80, respectively.
3. Maximum factored beam loads in table are given in total uniform load( W * Span) and based on a uniformly loaded condition with simply supported ends. For other loading and support conditions, see page 32 for applicable load and deflection modification factors.
4. Beams spans in table are assumed to be sufficiently laterally braced. Unbraced spans may reduce beam load carrying capacity. See page 49 for reduction factors for unbraced conditions.
5. Profile weight, 4.43 lbs / ft( 64.67 N / m), must be deducted from maximum factored beam load values. 6. C. G. is the‘ Center of Gravity’ of the cross section. 7. ** indicates KL / r for compression exceeds 200. 8. Maximum factored load at girder face assumes K value of 0.8.
