3.0 MODULAR SUPPORT SYSTEM 3.1.2 MT BEAM AND COLUMN LOAD TABLES
Modular Support Systems Technical Guide, Edition 1
Table 52- MT-90 Maximum Factored Beam Loads: X-axis and Y-axis Bending 1, 2, 3, 4, 5
Span in( cm)
Max Factored Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
24
30,935
0.05
30,935
30,935
30,935
( 61.0)
( 137,605)
( 0.12)
( 137,605)
( 137,605)
( 137,605)
36
20,620
0.11
20,620
20,620
18,735
( 91.4)
( 91,720)
( 0.28)
( 91,720)
( 91,720)
( 83,335)
48
15,465
0.20
15,465
15,465
10,535
( 121.9)
( 68,790)
( 0.50)
( 68,790)
( 68,790)
( 46,860)
60
12,370
0.31
12,370
10,115
6,745
( 152.4)
( 55,020)
( 0.78)
( 55,020)
( 44,990)
( 30,000)
72
10,310
0.44
9,365
7,025
4,680
( 182.9)
( 45,860)
( 1.12)
( 41,655)
( 31,245)
( 20,815)
84
8,835
0.60
6,880
5,160
3,440
( 213.4)
( 39,295)
( 1.52)
( 30,600)
( 22,950)
( 15,300)
96
7,730
0.78
5,265
3,950
2,630
( 243.8)
( 34,380)
( 1.99)
( 23,415)
( 17,570)
( 11,695)
108
6,870
0.99
4,160
3,120
2,080
( 274.3)
( 30,555)
( 2.51)
( 18,500)
( 13,875)
( 9,250)
120
6,185
1.22
3,370
2,525
1,685
( 304.8)
( 27,510)
( 3.11)
( 14,990)
( 11,230)
( 7,495)
144
5,155
1.76
2,340
1,755
1,170
( 365.8)
( 22,930)
( 4.47)
( 10,405)
( 7,805)
( 5,200)
168
4,415
2.39
1,720
1,290
860
( 426.7)
( 19,635)
( 6.08)
( 7,650)
( 5,735)
( 3,825)
192
3,865
3.13
1,315
985
655
( 487.7)
( 17,190)
( 7.95)
( 5,845)
( 4,380)
( 2,910)
216
3,435
3.96
1,040
780
520
( 548.6)
( 15,275)
( 10.06)
( 4,625)
( 3,465)
( 2,310)
240
3,090
4.89
840
630
420
( 609.6)
( 13,740)
( 12.41)
( 3,735)
( 2,800)
( 1,865)
Table 53- MT-90 Maximum Factored Column
Loads 1, 2, 6, 7, 8
Unbraced Height in( cm)
Max Factored Load at Girder Face lbs( N)
K = 0.65 lbs( N)
Maximum Column Load Applied at C. G.
K = 0.80 lbs( N)
K = 1.0 lbs( N)
K = 1.2 lbs( N)
24
25,920
64,855
64,855
64,855
64,855
( 61.0)
( 115,295)
( 288,500)
( 288,500)
( 288,500)
( 288,500)
36
25,715
64,855
64,855
64,855
64,855
( 91.4)
( 114,395)
( 288,500)
( 288,500)
( 288,500)
( 288,500)
48
25,455
64,855
64,855
64,855
64,610
( 121.9)
( 113,245)
( 288,500)
( 288,500)
( 288,500)
( 287,410)
60
25,155
64,855
64,855
64,035
60,890
( 152.4)
( 111,905)
( 288,500)
( 288,500)
( 284,850)
( 270,850)
72
24,780
64,855
64,610
60,890
55,935
( 182.9)
( 110,235)
( 288,500)
( 287,410)
( 270,850)
( 248,820)
84
24,015
64,855
62,200
56,705
51,110
( 213.4)
( 106,845)
( 288,500)
( 276,675)
( 252,245)
( 227,355)
96
23,180
63,430
59,520
52,750
46,065
( 243.8)
( 103,130)
( 282,155)
( 264,770)
( 234,660)
( 204,905)
108
20,790
61,385
55,935
48,605
40,935
( 274.3)
( 92,495)
( 273,060)
( 248,820)
( 216,210)
( 182,105)
120
19,915
59,165
52,750
44,355
35,880
( 304.8)
( 88,585)
( 263,200)
( 234,660)
( 197,320)
( 159,620)
144
18,085
53,565
46,065
35,880
26,385
( 365.8)
( 80,450)
( 238,280)
( 204,905)
( 159,620)
( 117,375)
168
16,240
48,185
39,240
27,910
19,385
( 426.7)
( 72,255)
( 214,355)
( 174,545)
( 124,165)
( 86,250)
192
14,425
42,645
32,615
21,375
14,835
( 487.7)
( 64,185)
( 189,695)
( 145,080)
( 95,085)
( 66,005)
216
12,670
37,135
26,385
16,880
11,725
( 548.6)
( 56,365)
( 165,190)
( 117,375)
( 75,105)
( 52,175)
240
11,130
31,815
21,375
13,680
9,495
( 609.6)
( 49,510)
( 141,525)
( 95,085)
( 60,850)
( 42,245)
Notes:
1. Loads are based on ICC-ES ELC-5019 and CSA S136-16, the North American Specification for the Design of Cold-Formed Steel Structural Members( using the Appendix B provisions applicable to Canada), CSA Group.
2. Resistance factors for flexure and compression are 0.90 and 0.80, respectively.
3. Maximum factored beam loads in table are given in total uniform load( W * Span) and based on a uniformly loaded condition with simply supported ends. For other loading and support conditions, see page 32 for applicable load and deflection modification factors.
4. Beams spans in table are assumed to be sufficiently laterally braced. Unbraced spans may reduce beam load carrying capacity. See page 49 for reduction factors for unbraced conditions.
5. Profile weight, 6.01 lbs / ft( 87.74 N / m), must be deducted from maximum factored beam load values. 6. C. G. is the‘ Center of Gravity’ of the cross section. 7. ** indicates KL / r for compression exceeds 200. 8. Maximum factored load at girder face assumes K value of 0.8.
100
( 3-15 / 16“)
( 1 / 8“)
3
( 3-15 / 16“) 100
( 1-15 / 16“) 50
mm( in)
∅ 9.2
( 3 / 8“)
50
( 1-15 / 16“)
50( 1-15 / 16“)
