UH - < 70HRC - Corner radius
CUTTING PARAMETERS
INFO
UHCS4
Material
Group
ISO 513
P3

P5

K2

K3
P6

K4

H1

H4

H5
H2 H3
Hardness/Rm < 45 HRC 45 - 55 HRC 55 - 60 HRC 60 - 65 HRC
ap x ae 0.3D x D 0.2D x D 0.2D x D 0.1D x D
Vc (m/min)
SIDE MILLING
P4
90-130
D
(mm) n
(rpm)
1
2
3
4
5
6
8
10
12 30000
17520
11680
8760
7010
5840
4380
3500
2920
60-100
fn
Vf
(mm/rev) (mm/min)
0.010
0.020
0.030
0.040
0.045
0.050
0.065
0.085
0.100
1200
1400
1400
1400
1260
1170
1140
1190
1170
n
(rpm)
25480
12740
8490
6370
5100
4250
3180
2550
2120
50-70
fn
Vf
(mm/rev) (mm/min)
0.009
0.018
0.027
0.036
