KL-TECH s.r.o | www.klte.cz MEX - 30÷55HRC - Ball nose CUTTING PARAMETERS INFO MEXCLSB2 Material Group ISO 513 N TYPHOO HTA TA-HTA-4 N TYPHOO PU-HPU N TYPHOO ALH _ 45° N TYPHOO HRC N TYPHOO I SUH MIN N TYPHOO HL C-SD-TA ap ae COPYING LFTA SUTA /CO HSS-HSS DRILLS G2 MDTA P HF VH/U MEF ALU MEX UH -HSSP HSS/CO LS END MIL CARBIDE BURRS 580 P3 P4 K1 P4 K2 P5 P6 K3 K4 H1 H4 H5 Hardness/Rm < 1000 N/mm² < 35 HRC 35 - 45 HRC 45 - 55 HRC ap x ae 0.05D x 0.2D 0.05D x 0.2D 0.05D x 0.2D 0.05D x 0.2D Vc (m/min) 100-140 80-120 60-80 D D (eff .) (mm) (mm) N TYPHOO SUH P2 1 2 3 4 5 6 8 10 12 14 16 18 20 0.44 0.87 1.31 1.74 2.18 2.62 3.49 4.36 5.23 6.10 6.97 7.85 8.72 n (rpm) fn Vf (mm/rev) (mm/min) 38220 19110 12740 9550 7640 6370 4780 3820 3180 2730 2390 2120 1910 0.015 0.021 0.027 0.037 0.045 0.051 0.060 0.068 0.077 0.089 0.102 0.115 0.132 _ n (rpm) Vf (mm/min) 30° x 0.8 x 0.8 15° x 0.7 x 0.7 0° x 0.6 x 0.6 1150 810 690 700 690 650 570 520 490 490 490 490 500 n (rpm) 31850 15920 10620 7960 6370 5310 3980 3180 2650 2270 1990 1770 1590 fn Vf (mm/rev) (mm/min) 0.014 0.019 0.024 0.033 0.041 0.046 0.054 0.061 0.069 0.080 0.092 0.103 0.119 860 610 520 520 520 490 430 390 360 360 370 370 380 n (rpm) 22290 11150 7430 5570 4460 3720 2790 2230 1860 1590 1390 1240 1110 40-60 fn Vf (mm/rev) (mm/min) 0.012 0.017 0.022 0.029 0.036 0.041 0.048 0.054 0.061 0.071 0.082 0.092 0.106 530 380 320 330 320 300 270 240 230 230 230 230 230 n (rpm) 15920 7960 5310 3980 3180 2650 1990 1590 1330 1140 1000 880 800 fn Vf (mm/rev) (mm/min) 0.011 0.015 0.019 0.026 0.032 0.036 0.042 0.048 0.054 0.062 0.071 0.080 0.092 330 240 200 200 200 190 170 150 140 140 140 140 150
