KL-TECH s.r.o | www.klte.cz MEX - 30÷55HRC - Corner radius CUTTING PARAMETERS INFO MEXLS2R Material Group ISO 513 N TYPHOO HTA TA-HTA-4 N TYPHOO PU-HPU N TYPHOO ALH N TYPHOO HRC N TYPHOO I SUH MIN N TYPHOO HL C-SD-TA LFTA SUTA /CO HSS-HSS DRILLS G2 MDTA P HF VH/U MEF ALU MEX UH -HSSP HSS/CO LS END MIL CARBIDE BURRS 554 P3 P4 K1 P4 K2 P5 P6 K3 K4 H1 H4 H5 < 1000 N/mm² < 35 HRC 35 - 45 HRC 45 - 55 HRC ap x ae 0.3D x D 0.3D x D 0.2D x D 0.05D x D Vc (m/min) 70-110 50-90 30-70 2 3 4 5 6 8 10 12 16 < D3: ap = 0.4 mm max SLOTTING Hardness/Rm D (mm) N TYPHOO SUH P2 n (rpm) 14300 9600 7200 5700 4800 3600 2900 2400 1800 fn Vf (mm/rev) (mm/min) 0.009 0.012 0.018 0.024 0.029 0.035 0.041 0.050 0.065 260 230 260 270 280 250 240 240 230 n (rpm) 11440 7680 5760 4560 3840 2880 2320 1920 1400 fn Vf (mm/rev) (mm/min) 0.008 0.011 0.016 0.022 0.026 0.032 0.037 0.045 0.059 190 170 190 200 200 180 170 170 160 n (rpm) 8580 5760 4320 3420 2880 2160 1740 1440 1000 20-40 fn Vf (mm/rev) (mm/min) 0.007 0.010 0.014 0.019 0.023 0.028 0.033 0.040 0.052 125 110 125 130 135 120 115 115 105 n (rpm) 5150 3460 2590 2050 1730 1300 1040 860 600 fn Vf (mm/rev) (mm/min) 0.006 0.008 0.013 0.017 0.020 0.025 0.029 0.035 0.046 65 60 65 70 70 65 60 60 55
