HORIZONTAL INERTIAL TANK FOR COLD WATER AND HOT/COLD SYSTEMS

PRESSURE

APPLICATION
Water storage for hot/cold systems.
EXTERNAL LINING
Blue skai with plastic black caps for connections
MATERIAL
Outside painted mild steel, inside uncoated.

Tmax
-10 / +90 °C

INSULATION
20 mm fixed polyethylene not subject to condensation.
Not self-estinguishing version. Not removable from the
tank.
WARRANTY
2 years
See general sales conditions and warranty.

1

Model

100
200
300
500
800
1000
1500
2000
2500
3000
4000
5000

Art. Nr.
3001161031001
3001161031002
3001161031003
3001161031004
3001161031005
3001161031006
3001161031007
3001161031008
3001161031013
3001161031009
3001161031010
3001161031012

Drain

2

ACQ. REF. GC 20 OR
(with 20 mm not self-estinguishing
insulation)

Safety valve

3-4
5- 6

€
355,00
433,00
500,00
713,00
1.047,00
1.258,00
1.610,00
2.045,00
2.444,00
2.720,00
3.720,00
4.668,00

7
8

0

L1 (4) (7) (3)

Connections to the system
Connection for instrumentation 1/2” Gas F

INERTIAL

TECHNICAL DESCRIPTIONS
Horizontal inertial water tanks are used for hot/cold
systems in order to increase the thermal inertia and,
for those installations without a low water-capacity,
avoiding that the chilling generator is continually
working.

TEMPERATURE

Pmax
6 bar

P.E.D. product planned and produced in conformity to the article 3.3 of directive 92/23/CE

P.E.D. product planned and produced in conformity to the article 3.3 of directive 92/23/CE

VOLANO TERMICO CALDO-FREDDO GC 20 OR

L2 (6) (5)
H3

Df

H2 (1) (7)
(8) (2)

H1 (4) (6)
0
L3

[Kg]

Model
100
200
300
500
800
1000
1500
2000
2500
3000
4000
5000

Net
Volume
[liters]

32
53
68
102
148
170
184
220
284
330
452
