ACQUA REFRIGERATA ZINCATO ZC 20 VT
VERTICAL GALVANIZED CHILLED WATER TANK
PRESSURE
TEMPERATURE
Pmax
6 bar
Tmax
-10 / +60 °C
TECHNICAL DESCRIPTIONS
Vertical chilled water tanks are used for air conditioning
installations in order to increase the thermal inertia
and, for those installations without a low watercapacity, avoiding that the chilling generator is
continually working.
EXTERNAL LINING
Blue skai with plastic black caps for connections
INSULATION
20 mm fixed polyethylene not subject to condensation.
Not self-estinguishing version. Not removable from the
tank.
MATERIAL
Outside painted mild steel, inside uncoated.
CORROSION PROOF TREATMENT
These
tanks
are
galvanized
inside
and
outside, with immersion in a pool of fused
zinc with pureness
not below 99,99%
(Uni EN 1179))
APPLICATION
Storage of chilled water for air conditionig systems.
WARRANTY
2 years
See general sales conditions and warranty.
Df
ACQ. REF. ZC 20 VT
(20 mm Not self-estinguishing
insulation)
€
Art. Nr.
3001162130001
329,00
3001162130002
402,00
3001162130003
490,00
3001162130004
711,00
3001162130005
1.081,00
3001162130006
1.331,00
3001162130107
1.804,00
3001162130108
2.183,00
3001162130113
2.677,00
3001162130109
3.143,00
3001162130110
4.625,00
3001162130112
5.591,00
(2)
PROMPT DELIVERY
Model
1-5 days to dispatch
(delivery time excluded)
100
200
300
500
800
1000
1500
2000
2500
3000
4000
5000
H4 (3)
(7) (4)
H
A
H3 (8)
1
Drain
2
H2 (5)
(6)
Safety valve
3-4
5- 6
H1 (1)
0
100
200
300
500
800
1000
1500
2000
2500
3000
4000
5000
Weight
Net Volume
[Kg]
Model
[liters]
32
53
67
101
147
170
183
219
274
321
442
565
101
190
292
501
788
1034
1432
1970
2300
2908
3749
4964
Df
H
7-8
A
H1
H2
H3
H4
Connections to the system
Connection for instrumentation 1/2” Gas F
1-2
[mm]
400
450
550
650
750
850
950
1100
1250
1250
1400
1600
1006
1407
1518
1810
2108
2162
2351
2421
2289
2804
2878
2916
1017
1415
1529
1821
2119
2178
2386
2437
2304
2826
2904
2948
73
68
129
121
108
96
121
105
149
149
133
111
202
3-4-5-6
7-8
Connections Gas F
287
297
404
441
458
479
490
509
619
619
648
656
592
927
994
1241
1458
1479
1700
1719
1519
1919
1948
1956
792
1177
1244
C
