Extracting Oil and Grease from Aqueous Samples
H
orizon Technology’s SPE-DEX®
3000XL extractor provides an
alternative to expensive, labour-intensive liquid-liquid extraction (LLE)
methods for extracting oil and grease
from aqueous samples. Using a combination of advanced liquid handling and
‘Certified for Automation’ Pacific O&G
SPE disks, the SPE-DEX 3000XL
delivers the accuracy and consistency data
laboratories need to comply with Method
1664A and 1664B QC specifications.
The SPE-DEX 3000XL extractor is
Closed Cup
Flashpoint
Tester
S
tanhope-Seta’s new Pensky-Martens
Closed Cup Flashpoint Tester is
Monitoring and Control Laboratories
exciting new edition to its already impressive flashpoint tester range.
Test methods:
ASTM D93, ASTM
E502, IP 34, IP 35,
IP 404 (obs),
AASHTO
T73-811,
BS 2000
Parts 35 &
404 (obs),
EN 22719, FTM 791 1102, ISO 15267,
ISO 2719, JIS K2265, NF M07-019
Features:
• Temperature range from ambient to
400°C
• Easy operation with intuitive software
• Large resistive touchscreen display
• Air bath and heater design that is
optimised for sample cooling
• Optional fast heating for rapid and
efficient testing
• A design suited for safety with ‘quick
lift’ lid lifting arm and integrated fire
extinguisher
• Overheating protection and automatic
shut-off
• Modern, compact and robust design. ⚛
Monitoring & Control Laboratories
Tel: 011-608-4664
Fax: 011-608-4741
Email: [email protected]
a three-station system,
and is automated
allowing unattended operation. It processes
samples directly
from the original
sample bottle.
It automatically
delivers all solvents, regulates
sample processing and disk drying
times, rinses the sample bottle
and collects the extract. The
3000XL extractor is capable
of handling any combination
of 47, 50 and 100mm disks.
The sample inlet valve allows
for the most challenging
samples to be processed.
The extractor can be used
with the Solvent Trap™
Recovery system, which
captures up to 70% of the
n-hexane solvent
vapour from EPA Method 1664A oil and
grease extractions. It can also be used
with the Speed-Vap™ III Solvent Evaporation system, which provides safe and
fast evaporation of n-hexane solvent. ⚛
Microsep
Contact: Louis van Huyssteen
Tel: 011-553‑2300
Email: [email protected]
