SOLID END MILLS
4fl
35°
FACE
MILLING
SHOULDER
MILLING
PLUNGING
EQUAL
90° 4 FLUTE, LONG
DESIGNATION GRADE D1 D2 L1 L2 CATALOG #
E90 Z4 D03.0(06) L12.0(070) LT 40 3 6 70 12 M5005524
E90 Z4 D04.0(06) L15.0(070) LT 40 4 6 70 15 M5005525
E90 Z4 D05.0(06) L20.0(080) LT 40 5 6 80 20 M5005526
E90 Z4 D06.0(06) L20.0(080) LT 40 6 6 80 20 M5005527
E90 Z4 D08.0(08) L25.0(100) LT 40 8 8 100 25 M5005528
E90 Z4 D10.0(10) L30.0(100) LT 40 10 10 100 30 M5005529
E90 Z4 D12.0(12) L40.0(110) LT 40 12 12 110 40 M5005530
E90 Z4 D16.0(16) L50.0(140) LT 40 16 16 140 50 M5005531
CUTTING SPEED
p. 290
DOC / FEED
p. 291 - 302
157
