MILLING
CUTTERS RX..
d
L
Ap
D1
D
SHELL MILL - RX.. 10T3 M0
Ap Z 40 5 5 5.5 M2003442
40 5 6 α 4.0 M2001568
22 40 5 5 4.0 M2001569
42 22 40 5 6 4.0 M2001570
63 53 22 40 5 7 3.0 M2001571
LT 101 M-W-D066/6 66 56 22 40 5 6 2.6 M2001572
LT 101 M-W-D066/7 66 56 22 40 5 7 2.6 M2001573
DESIGNATION
D
D1
d
LT 101 M-W-D040/5 40 30 16
LT 101 M-W-D050/6 50 40 22
LT 101 M-W-D052/5 52 42 LT 101 M-W-D052/6 52 LT 101 M-W-D063/7
L
SCREW
KEY
CATALOG #
M2003786
M2000602
SHELL MILL - RX.. 1204 M0
D D1 d L Ap Z LT 121 M-W-D040/4 40 28.0 16 40 6 4 7.5 M2001855
LT 121 M-W-D050/5 50 38.0 22 40 6 5 α 5.0 M2001856
LT 121 M-W-D052/5 52 40.0 22 40 6 5 5.0 M2001857
LT 121 M-W-D063/7 63 51.0 22 40 6 7 3.0 M2001858
LT 121 M-W-D066/6 66 54.0 22 40 6 6 3.0 M2001859
LT 121 M-W-D066/7 66 54.0 22 40 6 7 3.0 M2001860
LT 121 M-W-D080/7 80 68.0 27 50 6 7 2.5 M2001861
LT 121 M-W-D080/9 80 68.0 27 50 6 9 2.5 M2001862
DESIGNATION
SCREW
KEY
CATALOG #
M2000597
M2000602
131
