MILLING
KL-TECH s.r.o | www.klte.cz
CUTTERS RX..
Ap
d
D1 D
L1
SCREW COUPLING - RX.. 10T3 M0
D D1 d L1 Ap Z LT 101 S-W-D025/3 25 15 M12 35 5 3 10.0 M2001574
LT 101 S-W-D032/3 32 22 M16 35 5 3 α 8.5 M2001575
LT 101 S-W-D032/4 32 22 M16 35 5 4 8.5 M2001576
DESIGNATION
CATALOG #
SCREW
KEY M2003786
α CATALOG #
M2000602
SCREW COUPLING - RX.. 1204 M0
DESIGNATION
LT 121 S-W-D040/4
D D1 d L1 Ap Z
40 28.0 M16 40 6 4
7.5
SCREW
KEY
132
M2001863
M2000597
M2000602
