MILLING
CUTTERS RX..
Ap
d
D1 D
L1
L
END MILL RX.. - 10T3 M0
D D1 d L L1 Ap Z LT 101 C-W-D025/3 25 15 25 117 60 5 3 10.0 M2001562
LT 101 C-W-D032/4 32 22 32 131 70 5 4 α 8.5 M2001563
LT 101 CL-W-D032/3 32 22 32 181 70 5 3 8.5 M2001564
LT 101 W-W-D025/3 25 15 25 92 35 5 3 10.0 M2001565
LT 101 W-W-D032/4 32 22 32 101 40 5 4 8.5 M2001566
LT 101 WL-W-D032/3 32 22 32 181 120 5 3 8.5 M2001567
DESIGNATION
SCREW
KEY
CATALOG #
M2003786
M2000602
END MILL RX.. - 1204 M0
DESIGNATION
D D1 d L L1 Ap Z
LT 121 C-W-D040/4 40 28.0 40 141 70 6 4
LT 121 W-W-D040/4 40 28.0 40 111 40 6 4
α
M2001853
7.5 M2001854
SCREW
KEY
130
CATALOG #
7.5
M2000597
M2000602
