had previously been considered essential components of crank presses . The DSF-U series includes a newly developed energysaving hydraulic power unit equipped with a flywheel . Multi-stage knockout functionality can be accommodated by mounting hydraulic cylinders in the bed on the left and right that actuate a central knockout bar . Basic operations can be performed from a central location at the front of the press , including confirmation of the crank angle , die height settings and load monitoring during forming . We provide a wide array of options for DSF-U presses to meet detailed customer requirements ,” highlighted AIDA .
Below : Bi-polar plate .
DSF-NE2 servo press
Battery cases are containers for chemical reagents and must resist highly corrosive electrolytes . Together with electric motors , they represent the base of e-mobility . The production of battery cases requires highthroughput presses .
In early 2021 , AIDA unveiled its new DSF- NE2 , a monolithic two-point servo press that combines the high rigidity of one-piece frame with the flexibility of the fully programmable servo motion of AIDA DSF ® technology . DSF-NE2 presses are equipped with AIDA ’ s high-torque , low-speed servo motor for metal forming and stamping . Every frame component is designed and verified with FEM systems .
“ The zero-clearance roller guide requires no lubrication and contributes significantly to longer die life . The DSF-NE2 series of presses provide low-noise , low-vibration precision forming , optimising all production and maintenance operations while ensuring maximum application flexibility and long die life . This series of presses is capable of speeds of 120 strokes per minute ,” commented AIDA .
The DSF-NE2 series was awarded Product of the Year in the “ Metal Forming and Punching ” category at the EuroBLECH Awards 2022 .
“ AIDA DSF ® ( Direct Servo Former ) servo presses offer unparalleled operability , even with a reduced number of forming stages . Thanks to the ‘ soft touch ’ function , which causes the punch to slow down when it comes into contact with the material , they can guarantee a significant increase in the overall quality of the parts produced without compromising on productivity ,” continued AIDA .
The AIDA DSF-NE2 4000 press .
The manufacturer has developed an energy control architecture that replaces the kinetic energy storage capacity of a flywheel with the electrical energy storage capacity of capacitors . In fact , the peak electrical energy required during the forming phase is predominantly provided by the electrical energy previously stored in capacitors , leading to “ an energy demand from the power grid comparable to that of a mechanical press .”
“ All AIDA DSF ® servo presses use proprietary AIDA servo motors specifically developed for forming operations , capable of offering five times the performance of a standard commercial servo motor ,” concluded the press specialist .
Meet AIDA on Pad 14 , stand D10 , at LAMIERA in Milan , Italy ( 10-13 May 2023 ), and at CWIEME Berlin , Germany ( 23-25 May 2023 ) on stand 3.2 / B24 . n
www
. aida-europe . com
Battery case lids . AIDA ’ s DSF-U series press .
