GEODYNA® RANGE
2D SAPE WHEEL BALANCERS
geodyna 3900 - EEWB743AE1
The geodyna 3900 is a professional video balancer for car, light
truck and motorcycle wheels which combines high accuracy with
a small footprint. A perfect solution for garages that want to
optimise the working space.
Scope of application:
Garages and small to medium tyre shops.
Features
• VPM (virtual plane measuring) - enhanced
measuring to give higher accuracy results
• Automatic start of measurement when hood
closed & brake applied at end of spin cycle
• Robust 40mm shaft
• 5 different options for weight positioning on
wheel
• 2D SAPE - Automatic entry of wheel diameter
and wheel distance
• Guided weight positioning in Alu mode using gauge arm weight applicator
• Split weight mode - Hide weights behind
wheel spokes for more appealing cosmetic
finish
Te c h n i c a l S p e c i f i c a t i o n
• Tyre matching mode - optimise tyre to rim so
using less weights
Rim centre bore diameter
43 - 116 mm
Shaft diameter
40 mm
• 19" monitor
Measuring speed
200 rpm
Measuring time
6 sec
Display / Monitor TFT Monitor
19" LCD
• User friendly graphical display
Rim diameter / Manual Input
8 - 25" / 8 - 30"
• Wheel guard
Wheel width max.
508
