GEODYNA® RANGE
2D SAPE WHEEL BALANCERS
geodyna 990-2 - 6028746
Digital multi plane motorised wheel balancer with LCD display.
Scope of application:
Garages and small to medium tyre shops.
Features
• VPM (virtual plane measuring) for enhanced
measuring to give higher accuracy results
• Robust 40mm shaft
• 5 different options for weight positioning
on wheel
• 2D SAPE - Automatic entry of wheel diameter
and wheel distance
• Guided weight positioning in Alu mode - using
gauge arm weight applicator
• Split weight mode - Hide weights behind wheel
spokes for more appealing cosmetic finish
• Tyre matching mode - optimise tyre to
rim so using less weights
• Tapered shaft
Te c h n i c a l S p e c i f i c a t i o n
Rim centre bore diameter
43 - 116 mm
Shaft diameter
40 mm
Measuring speed
< 100 rpm
Measuring time
6 - 9 sec
Display / Monitor TFT Monitor
LCD
Rim width
1 - 20"
Rim diameter / Manual Input
8 - 25" / 8 - 30"
Wheel width max.
530 mm
Wheel diameter max. (w/o wheel guard)
1117 mm
Wheel diameter max.
(with optional wheel guard)
900 mm
Wheel weight max.
70 kg
Input of distance machine / rim flange
semi-automatic / gauge arm
Dimensions (HxWxD)
970 x 930 x 580 mm
Power Supply
200-240 VAC 50/60 Hz
