GEODYNA® RANGE
2D SAPE WHEEL BALANCERS
geodyna 960-2 Fusion II - EEWB733AE4
Compact easy to use wheel balancer with small footprint
and LED display.
Scope of application:
Garages and small to medium tyre shops.
Features
• VPM (virtual plane measuring) for
enhanced measuring and higher
accuracy results
• Automatic start of measurement
when hood is closed & brake applied
at end of spin cycle
• Robust 40mm shaft
• 5 different options for weight
positioning on wheel
• 2D SAPE - Automatic entry of wheel
diameter and wheel distance
• Guided weight positioning in Alu
mode - using gauge arm weight
applicator
• Split weight mode - Hide weights
behind wheel spokes for more
appealing cosmetic finish
• Tyre matching mode - optimise tyre
to rim so using less weights
• Integrated flange
Te c h n i c a l S p e c i f i c a t i o n
Measuring speed
< 100 rpm
Accuracy
1g
Rim width
3 - 20"
Rim diameter
10 - 30"
Max. wheel width
500 mm
Max. wheel diameter
900 mm
Max. wheel weight
70 kg
Dimensions (W x D x H) with wheel guard open
1100 x 1050 x 1710 mm
Machine weight without adaptor
70 kg
Power supply
230 Volt, 1 ph / 50 – 60 Hz
