WHEEL ALIGNMENT
3 D
R A N G E
GEOLINER 680 GEN4 - EEWAEU713C5
The Geoliner 680 has many of the great features of the Geoliner 670 but
with some specification changes. The Geoliner 680 features this time with a
22" TFT wide-screen monitor for enhanced visibility as well as featuring with
HOFMANN’s “Platinum” software package. Furthermore it comes with the
optional TIP (Target Imaging Pointer) for ride height measurement.
Features
• Vehicle Orientation Directional Indicator (VODI) guides the
technician through the measuring process
• PC with icon based PRO42 premium user software
• Ultra high resolution cameras
• Extra light ultra high resolution targets with universal wheel clamps
11" - 22"
• Optional drive-on camera for easy positioning of the vehicle on the lift
• 25 years plus of complete & up to date OEM specs
• Lift version incl. lifting equipment (flexible work level 0 - 2.0 m)
• Mobile terminal
• 22" TFT wide-screen monitor, colour printer
• Integrated OEM procedures
• 3D all readings screen
• 3D animation graphics
• Advanced measurement of vehicle dimensions – live
• EZ Toe for easy and convenient adjustment of toe on lock
• EZ Access for measurement with demounted wheels
• Optional TIP (target imaging pointer) for ride height measurement
Te c h n i c a l S p e c i f i c a t i o n
Toe-out on turns
Yes
Steering angle max.
Yes
A-arm adjust
Yes
Camber at zero toe (front axle)
Yes
Clamping range (Inch)
11 - 22"
Cradle adjust
Yes
Advanced vehicle dimensions live
Yes
Ackermann angle
Yes
Drag link adjust
Yes
Rolling Radius / Tyre diameter
Yes
Ride height modified vehicle specs
Yes
Single tie rod adjust
Yes
Steering asymmetry with diagnostics
Yes
FrameCheck™ light-truck frame angle
Yes
Rear shims
Yes
Caster and SAI turntable
Yes
Caster, ca
