F A S T. A C C U R A T E . E A S Y. P R O F I T A B L E
3 D
R A N G E
GEOLINER 790 - EEWAEU533B1
Features
The Geoliner 790 is a wireless system which provides
flexible installation, usage and mobility options.
Patented digital camera tracking, automatically
adjusts to the height of the vehicle.
• Productivity enhancing software
VERSATILE, ACCURATE HARDWARE
• Cross diagonal – Identify frame and structural issues before alignment
adjustments are made
Wireless communication means
it eliminates
connections between the camera towers and the
cabinet easing mobility, and providing a variety of
installation configurations. The Continuous third
camera calibration provides accurate readings and
reliable alignment results.
• Automated caster sweep – Automatically detects when the steering wheel is
turned and initates the caster sweep function
• Rolling radius – Identify mismatched tyre sizes - a potential cause of vehicle
pulling and drive train damage
• A-Arm adjust – Compound meter provides visual reference for simultaneous
caster and camber adjustment for vehicels and adjustable control arms
• EZ toe – Turn the front wheels and access difficult adjustment points while still
displaying centred toe readings
• Cradle adjust – Compound meter provides visual reference for simultaneous SAI
and caster adjustment for vehicles with front sub-frames/cradles
• Hardware and advanced design
SPEED AND PRODUCTIVITY
The ‘automatic vehicle height tracking camera
system’ follows the height of the vehicle, eliminating
the need to adjust the aligner when you move the
lift. Get readings in less than two minutes on a
wide variety of vehicles and wheel sizes owing to
its comprehensive vehicle specification database.
With regular updates, the geoliner 790 ensures you
always have the information to do the job right.
• Automatic vehicle height tracking
• rive through configuration
D
• ireless comunication and high mobility
w
• Help videos
Te c h n i c a l S p e c i f i c a t i o n
Tyre diameter
19 - 39"
Track width
48 - 96"
Wheel base
79 - 180"
Shipping weight
501 lbs
Power requirements
100 - 240 V 1PH 50/60 Hz
UL201, C22.2, CE Approved
AC400 Clamps
Secure clamping without touching the rim
• Fits all standard product cars
• Only the tyre is contacted
• Clutch limited damping force ensures accurate and repeatable results
• Durable and lightweight magnesium construction
• Optional Rim clamp kit available
Fast and easy to use
• Clamping is accomplished with a single fast-action adjustment knob
• No accessories needed to accomodate the full range of tyre sizes
• Large, ergonomically designed handle allows for easy and comforatable use.
