F A S T. A C C U R A T E . E A S Y. P R O F I T A B L E
3 D
R A N G E
GEOLINER 670 GEN4 - EEWAEU715C5
The new HOFMANN Gen4 wheel aligners will help to make
garage technicians alignment experts. These versatile aligners are
easy to use, reduce correction times and increase shop efficiency.
With the unique Gen4 imaging alignment system, the HOFMANN
Gen4 wheel aligners leverage patented imaging technology, to
provide accurate real-time measurements that reduce set-up and
measurement times and generate serious productivity benefits
for garages. This proven technology combines with easy-touse software to give professional garage technicians accurate
readings in a matter of minutes.
Ultra high resolution (UHR) cameras work as a coupled system
to produce real-time alignment readings and diagnostic data. In
less than 90 seconds the Gen 4 wheel aligners use a new design
in wheel targets and advanced software to provide 3D modelling
of the wheel position, thus eliminating missed collision damage
or mismatched tyres and wheels.
The versatile wheel clamps with industry-proven grips provide a
solid, worry-free attachment. The patented positioning procedure
is applicable to a wide range of vehicles without hardware
changes. No additional adaptors are needed to measure vehicles
with custom wheels and tyres.
Features
Te c h n i c a l S p e c i f i c a t i o n
Toe-out on turns
Yes
Camber at zero toe (front axle)
Yes
• Vehicle Orientation Directional Indicator (VODI) guides the technician
through the measuring process
Vehicle dimensions live
Yes
SAI increased
Yes
• PC with icon based PRO42 advanced user software
Steering angle max.
Yes
• Ultra high resolution cameras
Ride height modified vehicle specs
Yes
• Extra light ultra high resolution targets with universal wheel clamps 11"- 22"
FrameCheck™ light-truck frame angle
Yes
• Optional drive-on camera for easy positioning of the vehicle on the lift
Caster, camber, toe turntable live
Yes
• Complete and up-to-date OEM specs
Caster, camber, toe elevated live
Yes
• Lift version incl. lifting equipment (flexible work level 0 –2.0 m)
EZ Toe
Yes
• Mobile terminal
A-arm adjust
Yes
• 19" TFT wide-screen monitor, colour printer
Cradle adjust
Yes
• 3D all readings screen
Drag link adjust
Yes
Single tie rod adjust
Yes
Rear shims
Yes
Communication
Optical
Measuring system
3D
Clamping range (Inch)
11 - 22”
Power supply
230 VAC 1ph 50/60 Hz
• Automated caster sweep
• 3D animation graphics
• Live measurement of vehicle dimensions
• On-line help with 3D animation graphics
• EZ Toe for easy and convenient settings at maximum steering angle
• A-arm adjustment
• Cradle adjustment
®
