INFO
Please also pump the tire to test the airtight before hitting on the road for ensuring the Aegis Tire Checker is well settled.
NOTICE
• The Aegis Tire Checker is only compatible with Presta valve, both inner tube or tubeless system is applicable but the valve core needs to be removable.
• The Aegis Tire Checker has an applicable valve stem length ranging between 16-24mm, measuring from the lower level above the stem locknut to the top of the valve stem( not including the valve core).
• The Aegis Tire Checker parts will not be able to be engaged with each other if the stem length doesn’ t meet the applicable range.
• The Aegis Tire Checker parts will not be able to be engaged with each other if the stem length doesn’ t meet the applicable range.
Pairing the Aegis Tire Checker with your e-bike
The Aegis Tire Checker needs to be paired with your e-bike before the first use. The pairing can be done by both the remote controls or RideControl app:
1. RideControl app: E-bike Setup > Aegis Tire Checker Setup > Add Front / Rear Aegis Tire Checker > Scan the QR code or key-in the ID number on the side of Aegis Tire Checker
2. Remote controls: Settings > Accessories > Tire pressure sensor > Select Front or Rear Aegis Tire Checker > Select Bluetooth > Start scanning > Select the corresponding ID number on the side of the Aegis Tire Checker.
INFO
• The ID number is 12 characters.
• Making sure to download the latest version of the RideControl App to support the Tire Checker features.
16-24mm
valve stem locknut
4
