GAS & ELECTRIC
Elements
Ring Elements
Full Sheath , Single Heat
ITEM No.
253-1039
253-1042
253-1048
OD
6 1 ⁄ 16 " (154mm)
6 1 ⁄ 8 " (156mm)
6 19 ⁄ 32 " (168mm)
ID
4 5 ⁄ 16 " (110mm)
3" (76mm)
4 1 ⁄ 2 " (114mm)
VOLT
120
120
240
WATT
500
1000
750
Warmer
Elements
• 17 1 ⁄ 2 " L x 8 7 ⁄ 8 " W
• Incoloy
Definition:
Full Sheath : Metal covers entire element
(445mm x 225mm)
No. 144-1067 120 volt, 1000 watt
No. 202-1149 208 volt, 1000 watt
No. 144-1068 240 volt, 1000 watt
Strip Elements
• 1 1 ⁄ 2 "
(38mm)
wide
120 Volt, OT-Type
ITEM No.
LENGTH
17 7 ⁄ 8 " (454mm)
253-1094
23 3 ⁄ 4 " (603mm)
253-1074
240 Volt, OT-Type WATT
500
750
ITEM No.
253-1095
253-1099
253-1077 WATT
500
1000
1000
LENGTH
17 7 ⁄ 8 " (454mm)
17 7 ⁄ 8 " (454mm)
23 3 ⁄ 4 " (603mm)
Length
Warmer Elements
• 15 1 ⁄ 2 " L x 7 1 ⁄ 2 " W
• Incoloy
(394mm x 191mm)
No. 144-1065 120 volt, 1200 watt
No. 144-1066 240 volt, 1200 watt
Mounting hole centers are
1" (25mm) less than length
©2013 Franklin Machine Products
Tubular Cal Rod Heaters
Save time and money by bending your own cal rod heaters. Longer lengths are coiled or bent in half
for UPS shipment. Can be bent by hand without the use of tools.
• 1 ⁄ 4 " (6mm) diameter
• 24" (610mm) wire leads
• Incoloy sheath
ITEM No.
144-1000
144-1001
144-1002
144-1003
144-1004
144-1005
144-1006
144-1007
144-1069
144-1008
LENGTH
42" (1067mm)
45" (1143mm)
46" (1168mm)
55" (1397mm)
58" (1473mm)
72" (1828mm)
76" (1930mm)
88" (2235mm)
90" (2286mm)
95" (2413mm)
Immersion Element
without Thermostat
WATTAGE AT
120 VOLT 240 VOLT
300
1200
150
600
100
400
400
1600
125
500
200
800
600
2400
200
800
300
1200
500
2000
ITEM No.
144-1009
144-1010
144-1011
144-1012
144-1070
144-1013
144-1014
144-1015
144-1016
LENGTH
108" (2743mm)
110" (2794mm)
115" (2921mm)
120" (3048mm)
134" (3403mm)
136" (3454mm)
158" (4013mm)
190" (4826mm)
220" (5588mm)
WATTAGE AT
120 VOLT 240 VOLT
250
1000
800
3200
400
1600
600
2400
275
1100
400
1600
550
2200
500
2000
700
2800
No. 144-1050
• 208 volt 750 watt
• 19" rod length
• 3 phase
• Dishwasher- and booster-type
• 2" NPT mounting
• Incoloy
Length
Note: Lengths shown do not include wire leads.
©2103 Franklin Machine Products
