GAS & ELECTRIC
fuses
Ceramic Body Fuses
CARTRIDGE FUSES
WITH REJECT FEATURE
• Fast-acting-type
• 250 volt maximum rating
• 1 ⁄ 4 " x 1 1 ⁄ 4 " (6mm x 32mm)
REPLACES REPLACES
Buss
Littelfuse
–
ABC2 1 ⁄ 2
ABC3
314003
ABC
314010
ABC15 3AB/314 series
ABC20 3AB/314 series
ABC30
314030
AMP
2.5
3
10
15
20
30
No. 273-1043 3 amp
• Littlelfuse no. KLKR3
No. 253-1395 3 amp
• Buss no. KTK-R3
No. 253-1340 6 amp
• Buss no. KTK-R6
No. 187-1089 10 amp
• Replaces Buss no. KTKR10,
Littelfuse no. KLKR10
No. 253-1341 20 amp
• Buss no. KTK-R20
No. 253-1396 20 amp
• Buss no. LP-CC20
Glass Body Fuses
• SloBlo ® -type
• 32 VAC
• 1 ⁄ 4 " x 1 1 ⁄ 4 " (6mm x 32mm)
ITEM No.
253-1335
230-1041
253-1339
253-1336
253-1337
253-1338
AMP
1
3
5
10
15
20
REPLACES Buss
AGC1
AGC3
AGC5
AGC10
AGC15
AGC20
TIME DELAY FUSE
No. 518-1007
• 600 volt maximum rating
• Class CC
• Current limiting
• 30 amp
• 3 ⁄ 8 " OD x 1 1 ⁄ 2 " L (10mm x 38mm)
• Buss no. LP-CC30
• Class G
• Time delay
• 600 volt maximum rating
• 13 ⁄ 32 " (10mm) diameter
LENGTH
1 5 ⁄ 16 " (33mm)
1 5 ⁄ 16 " (33mm)
1 5 ⁄ 16 " (33mm)
1 5 ⁄ 16 " (33mm)
1 5 ⁄ 16 " (33mm)
1 5 ⁄ 16 " (33mm)
1 5 ⁄ 16 " (33mm)
1 5 ⁄ 16 " (33mm)
1 5 ⁄ 16 " (33mm)
1 5 ⁄ 8 " (41mm)
FUSE
No. 249-1069
• Fast-acting-type
• 250 volt maximum rating
• 30 amp
• 13 ⁄ 32 " OD x 1 15 ⁄ 32 " L (10mm x 37mm)
• Littelfuse no. BLN30
Glass Body Fuse
Cartridge Fuses
ITEM No. AMP
253-1172 1
253-1256 2
253-1167 3
253-1174 5
253-1343 6
253-1342 8
253-1168 10
253-1169 15
253-1170 20
253-1345* 30
No. 249-1073
• Fast-acting-type
• 250 volt maximum rating
• 13 ⁄ 32 " x 1 15 ⁄ 32 " (10mm x 37mm)
• 25 amp
• Littelfuse no. BLN25
ITEM No.
175-1121
253-1332
223-1011
253-1175
253-1176
253-1333
• 600 volt maximum rating
• Class CC
• Current limiting
FUSE
No. 288-1075
• 1.25 amp
• 250 volt maximum rating
• 1 ⁄ 4 " x 1 1 ⁄ 4 " (6mm x 32mm)
• Littlefuse no. 313
Glass Body Fuses
REPLACES REPLACES
Buss
Littelfuse
SC1
SLC1
SC2
SLC2
SC3
SLC3
SC5
SLC5
SC6
SLC6
SC8
SLC8
SC10
SLC10
SC15
SLC15
SC20
SLC20
SC30
SLC30
*480 volt maximum rating
Phone: [phone]
• SloBlo ® -type
• 250 volt maximum rating
• 1 ⁄ 4 " x 1 1 ⁄ 4 " (6mm x 32mm)
Cartridge Fuses
• Class G
• Time delay
• 480 volt maximum rating
• 13 ⁄ 32 " (10mm) diameter
No. 253-1257 40 amp
• Buss no. JJN40
No. 204-1134 50 amp
• Buss no. JJN50
24-Hour Fax: [phone]
No. 263-1066 1 ⁄ 10 amp
• Buss no. MDL1/10A
No. 263-1063 1 amp
• Buss no. MDL1A
No. 221-1001 2 amp
• Replaces Buss MDL2
• Replaces Littelfuse 3AG/313 series
No. 168-1529 3 amp
• Buss nos. BK/MDL3, MDL-3
• Littelfuse no. 313003
559
