GAS & ELECTRIC
Elements
Element Gasket
CHROMALOX ® Immersion
Elements
No. 144-1055
• 2 3 ⁄ 4 " x 2 3 ⁄ 4 " (70mm x 70mm)
• 1 3 ⁄ 4 " (44mm) screw centers
• 1 5 ⁄ 8 " (41mm) ID
• Ideal for use in steam tables and coffee urns
• Includes high limit (No. 144-1072)
• Requires 2 7 ⁄ 16 " mounting hole
• Supplied with gasket for watertight seal
240 VOLT
ITEM No.
Single Phase
144-1023
144-1031
144-1024
144-1032
144-1025
144-1033
144-1026
144-1035
3 Phase
144-1028
144-1036
144-1029
WATT LENGTH
3000
4000
5000
6000
7000 9"
10"
13"
15"
15"
5000
7000 11"
11"
ELEMENT GASKET
No. 230-1023
• 3" x 3" (76mm x 76mm)
• 2 3 ⁄ 8 " (60mm) screw centers
• 2 1 ⁄ 4 " (57mm) ID
208 VOLT
ITEM No.
Socket for
Snap-In Type Element
No. 170-1012
• 1 3 ⁄ 16 " (30mm) mounting hole centers
• 18" (457mm) leads
• Spring-type
CHROMALOX ®
THERMOSTAT KIT
No. 250-1027
• For steam tables
• 60° to 250°F
• 84" capillary
• DPST
• Kit includes indicator light, mounting plate,
and enclosure cover
No. 253-1416 Replacement screw
CHROMALOX ® HIGH LIMIT
No. 144-1072
• For Chromalox ® bow-tie-type immersion
elements only
• Includes wire leads, mounting screw,
wire connector, and wiring diagrams
Note: This high limit must be used with Chromalox ®
immersion elements ONLY.
These elements are clearly marked and
have a red plastic junction box cover.
SOCKET FOR
EZ ELEMENT
No. 211-1010
• Includes 1" (25mm) OD aluminum sleeve
• 1 3 ⁄ 16 " (30mm) mounting hole centers
• 18" (457mm) leads
• Spring-type
Immersion Heater Element
Length
No. 144-1058
• Ideal for use on hot water and booster heaters
• Includes gasket
• 208 volt, 5000 watt
• 9 3 ⁄ 4 " (248mm) long
• 2 1 ⁄ 2 " x 2 1 ⁄ 2 " (64mm x 64mm) mounting plates,
1 3 ⁄ 4 " (44mm) screw centers
• Stainless steel
No. 144-1055 Replacement element gasket
Elements for specific applications are shown in the Parts section
(listed alphabetically by manufacturer).
Phone: 800-257-7737
24-Hour Fax: 800-255-9866
557
