GAS & ELECTRIC
push switches
Push Switches
1
2
• 15 ⁄ 32 " (12mm) diameter nipple
• 5 ⁄ 16 " (8mm) long plunger
REF
No. ITEM No.
CONNECTIONS
1
149-1060 2 screw terminals ACTION
SPST NO 125V RATING 250V RATING
15 amp
10 amp
• Commonly used on Orb
• 15 ⁄ 32 " (12mm) diameter nipple
• 7 ⁄ 16 " (11mm) long plunger
REF
No. ITEM No.
CONNECTIONS
2
149-1064 3 wire leads ACTION
SPDT On/On 125V RATING 250V RATING
3 amp
1 amp
MICROswitches
MICROSWITCHEs
• Normally open/normally closed terminals
• 15 ⁄ 16 " (24mm) screw center diagonally
• 3 ⁄ 16 " (5mm) tab terminals
• 10 amp at 125/250 volt rating
5
4
3
3. No.
4. No.
5. No.
6. No.
149-1086 Basic
149-1087 Lever
149-1088 Roller
230-1051* Lever
MICROSWITCH
7. No. 168-1424 Roller
• Normally open/normally closed terminals
• 1" (25mm) screw centers diagonally
• 1 ⁄ 4 " (6mm) tab terminals
• 16 amp at 125/250 VAC rating
• .5 amp at 125 VDC rating; .25 amp at
250 VDC rating
7
6
MICRO SAFETY SWITCH
8. No. 204-1246
• Normally open/normally closed terminals
• 1 ⁄ 4 " (6mm) tab terminals
• 20 amp at 125/250 volt rating
MICROSWITCH
8
532
9
9. No. 266-1125
• 15 amp at 125/250 volt rating
• Normally open/normally closed terminals
• 15 ⁄ 16 " (24mm) screw centers
• 3 ⁄ 16 " (5mm) tab terminals
* 15 amp at 125/250 volt rating
