REFRIGERATION
HINGES
REVERSIBLE UNIVERSAL DOOR HINGES
by CHG ®
Hinge
No. 123-1117
• 1 1 ⁄ 8 " (29mm) offset
• Chrome-plated bronze
• Kason no. 1055
Can easily be converted from left- to right-hand swing without
using tools. Designed to allow in-place adjustment.
• Universal mounting holes
• Lift-off capability
• Spring-assisted
• Satin chrome finish
No. 123-1283 Flush
• CHG no. W59-4000
3 3 ⁄ 8 "
5 3 ⁄ 8 "
(86mm)
(137mm)
12 7 ⁄ 8 "
No. 123-1284 1 1 ⁄ 8 " offset
• CHG no. W59-4112
10 1 ⁄ 4 "
(260mm)
2"
4 5 ⁄ 8 "
(51mm)
(117mm)
No. 123-1285 1 3 ⁄ 8 " offset
• CHG no. W59-4137
(327mm)
For important information on how to measure offsets, see the front of the Refrigeration section.
Hinge Hinge Hinge
No. 123-1020
• 1 1 ⁄ 8 " (29mm) offset
• Stainless steel
• Polar no. 414 No. 123-1099
• 1 1 ⁄ 8 " (29mm) offset
• Zinc-plated cast iron
• Kason no. 1214 No. 123-1229
• Flush mount
• Chrome-plated
• Replaces Standard Keil no. 2866
• Kason no. 1241
• Polar no. 109
14 1 ⁄ 2 "
13 ⁄ 8 "
1
4 3 ⁄ 8 "
(111mm)
(368mm)
10 3 ⁄ 8 " (264mm)
(333mm)
3 1 ⁄ 4 "
(83mm)
Phone: [phone]
5 7 ⁄ 16 "
(138mm)
3 1 ⁄ 4 "
(83mm)
24-Hour Fax: [phone]
4 1 ⁄ 4 "
(108mm)
2 5 ⁄ 8 "
(67mm)
255
